Product description: 7-inch tft display uses automotive-grade LCD and backlight materials, supports wide temperature operation of -30℃~85℃, is compatible with complex electromagnetic environments, meets the harsh conditions of the automotive industry, and is widely used in heavy trucks, light trucks, buses, new energy passenger cars and other automotive instruments. 7 inches has multiple resolutions: 800*480, 1024*600, 1280*800. EASTERN DISPLAY ─ Global Display Solution Expert ✅ Trusted choice of multinational customers Serving customers in 20+ countries including China, Germany, the United States, Poland, etc., providing customers with 1000+ custom tft display solutions ✅ Strict ...
7-inch tft display uses automotive-grade LCD and backlight materials, supports wide temperature operation of -30℃~85℃, is compatible with complex electromagnetic environments, meets the harsh conditions of the automotive industry, and is widely used in heavy trucks, light trucks, buses, new energy passenger cars and other automotive instruments. 7 inches has multiple resolutions: 800*480, 1024*600, 1280*800.
EASTERN DISPLAY ─ Global Display Solution Expert
✅ Trusted choice of multinational customers
Serving customers in 20+ countries including China, Germany, the United States, Poland, etc., providing customers with 1000+ custom tft display solutions
✅ Strict environmental standards
All products are RoHS/REACH certified.
✅ Precise adaptation capability
Provides full-size coverage from 2.0"-15.6", with optional resolutions from 240×320 to 1920×1080.
✅ Provide customized services:
The following customized services can be provided to customers:
1. Customized backlight brightness.
2. Cover thickness, shape and silk screen are optional.
3. Tempered cover AR/AG/AF treatment.
4. OCA full lamination.
5. Customized shell structure.
6. RTP/CTP are optional.
7. IP65 protection level is optional.
| Manufacturer | EASTERN DISPLAY |
| Resolution | 800*480、1024*600、1280*800 |
| Interface | RGB interface/LVDS interface |
| Connection method | FPC |
| Display type | 16.7M color TFT display |
| Viewing angle | Free |
| Operating voltage | 3.3V |
| Backlight type | LED backlight |
| Backlight brightness | 1000cd/m2 |
| Operating temperature | -30-85 ℃ |
| Storage temperature | -40-85 ℃ |
| Cover | Provide customized services such as AF/AG/AR. |
| Touch | Provide customized services for capacitive touch screen/resistive touch screen |
| Keywords:custom tft display/spi tft display/mini tft display/tft display touch screen/Customized TFT/ips tft display/i2c tft display/cheap tft display/tft screen for car. | |
Product description: mini oled display module, resolution 64*32, I2C interface, ultra...
Product description: This product is an automotive instrument tft display, with a res...
Product description: Segment LCD is widely used in industrial instruments, industrial...
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses FSTN mode, displays blue and black characters on a gray background, with high contrast and wide viewing angle. The module contains a driver chip and adopts COG production technology. The product is light and thin with low power consumption. It is connected to the main control MCU through the SPI interface or 8-bit parallel LCD interface to display various images and texts.
Product description: HTN LCD types are widely used in industrial instruments, industr...
FSTN is widely used in industrial instruments, industrial control equipment and communication equ...
This product is an LCD 20×4 character dot matrix display module, which is used for ASCII character display, with 4 lines and 20 characters per line. The display screen uses STN yellow-green mode LED backlit LCD, which displays black characters on a yellow-green background, with high contrast and wide viewing angle. The module contains the ST7066 universal character driver chip, adopts COB production technology, and is connected to the main control MCU through an 8-bit parallel LCD interface, which is easy to use.
Product description: Liquid Crystal Light Valve is a technical device that uses the c...
Product description: Low-power segment LCD is a display technology widely used in ele...
Product description: VA LCD products have high contrast, can display multiple colors,...
Product description: HTN LCD products have high contrast, wide viewing angle, clear d...
This product is a 240128 LCD dot matrix display that can display graphics with 240 columns x 128 rows of pixels. The display uses STN Negative mode LED backlit LCD, displays white text on a blue background, and has high contrast and wide viewing angle. The module contains a driver chip, uses COB and SMT production processes, and is connected to the main control MCU through an 8-bit parallel LCD interface to display various images and texts.
Product description: mini oled display, resolution 96*32, I2C interface, product ultr...
Product description: TFT LCD display screens are widely used in various commercial ve...
This product is an LCD 20×4 character dot matrix display module, which is used for ASCII character display, with 4 lines and 20 characters per line. The display screen uses STN yellow-green mode LED backlit LCD, which displays black characters on a yellow-green background, with high contrast and wide viewing angle. The module contains the ST7066 universal character driver chip, adopts COB production technology, and is connected to the main control MCU through an 8-bit parallel LCD interface, which is easy to use.
Product description: Antistatic LCD is a liquid crystal display with antistatic funct...
