This product is a high-definition TFT screen with a resolution of 1280720, an LVDS interface, and IPS technology for wide viewing angles. It features LED backlighting at 880 cd/m², ensuring clear visibility even in strong light environments. It supports operation across a wide temperature range of -30℃ to 85℃. Options include capacitive touch screens and tempered cover glass, meeting the demanding usage requirements of industrial products and automotive instrument clusters. It is widely used in new energy vehicle instrument clusters, HMI, industrial instruments, portable medical equipment, and more.
EASTERN DISPLAY – Global Display Solution Expert
✅ Trusted Choice for Multinational Clients
Serving clients in 20+ countries including China, Germany, USA, and Poland, providing 1000+ custom TFT display solutions.
✅ Stringent Environmental Standards
All products comply with RoHS/REACH certifications.
✅ Precise Adaptation Capability
Offers full-size coverage from 2.0" to 15.6", with resolutions optional from 240×320 to 1920×1080.
✅ Customized Services Provided:
The following customized services are available for clients:
1. Customized backlight brightness.
2. Optional cover glass thickness, shape, and screen printing.
3. Tempered cover glass AR/AG/AF treatment.
4. OCA/OCR full lamination service.
5. Customized enclosure structure.
6. RTP/CTP optional.
7. IP65 protection rating optional.
| Manufacturer | Eastern Display |
| Product model | EDT090HSLNX-21 |
| Resolution | 1280*720 |
| Interface | LVDS |
| Driver chip model | |
| Connection method | FPC |
| Display type | 16.7M color TFT display |
| Viewing angle | Free |
| Operating voltage | 3.3V |
| Backlight type | LED backlight |
| Brightness | 880cd/m2 |
| Operating temperature | -30-85℃ |
| Storage temperature | -40-85℃ |
| Cover panel | Provide customized services such as AF/AG/AR. |
