This mini OLED display features a 128×64 resolution and supports multiple interface options including I2C/spi serial ports. With a luminance of 220cd/m² and an operating temperature range of-40℃ to 70℃, it delivers ultra-low power consumption, high contrast ratio, and wide viewing angles. The display ensures clear and eye-catching visuals, making it ideal for applications such as flow meters, gas detectors, and fire safety monitoring systems.
Eastern Display offers small-to-medium OLED displays with multiple color options for domestic and international clients. Available in white, yellow, red, blue, and circular designs, these displays support both FPC (Flexible Printed Circuit) plug-in and soldering solutions. The plug-in option allows direct mounting on PCBs without connectors, ensuring secure and reliable performance. All materials comply with RoHS standards, making them widely applicable in fire suppression systems, smart home appliances, precision measurement instruments, and intelligent devices.
| manufacturer | Eastern Display |
| Display type | OLED |
| resolution ratio | 128*64 |
| display color | white |
| IC | SSD1309 |
| outline dimension | 60.5×30×2mm |
| Field of view dimensions | 57×29.49mm |
| IC packaging mode | COG |
| working voltage | 1.65v-3.3v |
| Visible range | Free |
| joggle | I²C、SPI |
| luminance | 220cd/m2 |
| attended mode | FPC |
| working temperature | -40℃~70℃ |
| storage temperature | -40℃~80℃ |
Keywords: AMOLED display/i2C OLED display/flexible OLED display/OLED display 128x64/mini OLED display/OLED display module/ESP32 OLED display/round OLED display.
Product description: The light source of the translucent LCD segment code LCD screen ...
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses STN mode LED backlit LCD, which displays black text on a yellow-green background, with high contrast and wide viewing angle. The module contains a driver chip and adopts COG production technology. The product is thin and light, has low power consumption, and a wide temperature range. It is connected to the main control MCU through the SPI interface and is used to display various images and texts.
Product description: This industrial-grade TFT display screen, with a resolution of 1...
The FSTN dot-matrix LCD screen, featuring high contrast ratio, wide viewing angle, and low power consumption, stands as the ideal display solution for high-end flow meters. This LCD display operates in FSTN mode with 128×128 or 128×64 resolution, showcasing blue-black text on a gray background with exceptional contrast and wide viewing angles. The module incorporates driver chips manufactured through COG technology, delivering slim profile, low power consumption, and broad operating temperature range. Equipped with SPI interface or 8-bit parallel LCD interface for connection to main control MCU, it delivers high-quality image and text display with stable performance.
Product description: An i2c oled display with a resolution of 128*64 and an I2C inter...
Product description: 1.54 inch flexible oled display, resolution 128*64, parallel or ...
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses FSTN mode, displays blue and black characters on a gray background, with high contrast and wide viewing angle. The module contains a driver chip and adopts COG production technology. The product is light and thin with low power consumption. It is connected to the main control MCU through the SPI interface or 8-bit parallel LCD interface to display various images and texts.
This product is a 240128 LCD dot matrix display that can display graphics with 240 columns x 128 rows of pixels. The display uses STN Negative mode LED backlit LCD, displays white text on a blue background, and has high contrast and wide viewing angle. The module contains a driver chip, uses COB and SMT production processes, and is connected to the main control MCU through an 8-bit parallel LCD interface to display various images and texts.
LED segment display products are widely used in medical instruments such as blood glucose meters,...
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses FSTN mode LED backlit LCD, which displays blue and black characters on a gray background, with high contrast and wide viewing angle. The module contains a driver chip and adopts COG production technology. The product is light and has low power consumption. It is connected to the main control MCU through the SPI interface and is used to display various images and texts.
Segment display is widely used in industrial instruments, industrial control equipment and commun...
This product is an LCD 20×4 character dot matrix display module, which is used for ASCII character display, with 4 lines and 20 characters per line. The display screen uses STN yellow-green mode LED backlit LCD, which displays black characters on a yellow-green background, with high contrast and wide viewing angle. The module contains the ST7066 universal character driver chip, adopts COB production technology, and is connected to the main control MCU through an 8-bit parallel LCD interface, which is easy to use.
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses FSTN mode, displays blue and black characters on a gray background, with high contrast and wide viewing angle. The module contains a driver chip and adopts COG production technology. The product is light and thin with low power consumption. It is connected to the main control MCU through the SPI interface or 8-bit parallel LCD interface to display various images and texts.
Product description: VA LCD products have high contrast, can display multiple colors,...
Product description: TFT LCD display screens are widely used in various commercial ve...
This product is a 12232 LCD dot matrix display that can display graphics with 122 columns x 32 rows of pixels. The display uses STN yellow-green mode LED backlit LCD, which displays black text on a yellow-green background, with high contrast and wide viewing angle. The module contains a driver chip, adopts COB production technology, and is connected to the main control MCU through an 8-bit parallel LCD interface to display various images and texts.
