Product description: VA LCD type is widely used in industrial instruments, industrial control equipment and communication equipment such as flow meters, microcomputer protection devices, recorders, energy meters, handheld meters, digital display meters, measuring meters, test meters, etc. LCD segment display digitally displays the measurement results, parameters, status information of instruments and meters, and the operating status, alarm information, and operation interface of industrial control equipment and communication equipment. EASTERN DISPLAY provides thousands of customized segment VA LCD screens for customers in North America, Europe, East Asia, etc. The number of products ...
VA LCD type is widely used in industrial instruments, industrial control equipment and communication equipment such as flow meters, microcomputer protection devices, recorders, energy meters, handheld meters, digital display meters, measuring meters, test meters, etc. LCD segment display digitally displays the measurement results, parameters, status information of instruments and meters, and the operating status, alarm information, and operation interface of industrial control equipment and communication equipment.
EASTERN DISPLAY provides thousands of customized segment VA LCD screens for customers in North America, Europe, East Asia, etc. The number of products produced each year exceeds 10 million. Based on many years of product development and production experience in serving customers of industrial instruments, industrial control equipment and communication equipment, it has rich technical accumulation in product design, core parameters and product demand concerns. It can provide customers with high-quality and cost-effective segment VA LCDs in a continuous and stable manner.
| Manufacturer | EASTERN DISPLAY |
| Display type | VA LCD |
| Viewing angle | 6/12 0’ CLOCK (custom made) |
| Operating voltage | 3.0V ---5.0V (custom made) |
| Backlight type | led segment display (custom made) |
| Backlight color | (custom made) |
| Operating temperature | -40℃-70℃(custom made) |
| Storage temperature | -40℃-85℃(custom made) |
| Display life | 100,000-200,000 hours (custom made) |
| ROHS standard | YES |
| REACH standard | YES |
| Applicable fields and scenarios | Industrial instruments, industrial control equipment, communication equipment, etc. |
| Product features | Gradient color |
| Keywords：Segment LCD/Custom LCD/Tester LCD/LCD display tester/LCD Manufacturer/Low Cost LCD/High contrast LCD/TN LCD/HTN LCD/STN LCD/FSTN LCD | |
Product description: Segment LCD screen with built-in touch screen Touch LCD segment ...
Product description: This industrial-grade TFT display screen, with a resolution of 1...
Product description: STN LCD type is widely used in industrial instruments, industria...
Product description: VA LCD products have high contrast, can display multiple colors,...
Product description: Segment LCD is widely used in industrial instruments, industrial...
Product description: Liquid Crystal Light Valve is a technical device that uses the c...
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses STN yellow-green mode LED backlit LCD, which displays black text on a yellow-green background, with high contrast and wide viewing angle. The module contains a driver chip, adopts COB production technology, and is connected to the main control MCU through an 8-bit parallel LCD interface to display various images and texts. The internal compensation circuit enables the module to achieve good display effects even when used in a wide temperature range.
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses STN yellow-green mode LED backlit LCD, which displays black text on a yellow-green background, with high contrast and wide viewing angle. The module contains a driver chip, adopts COB production technology, and is connected to the main control MCU through an 8-bit parallel LCD interface to display various images and texts. The internal compensation circuit enables the module to achieve good display effects even when used in a wide temperature range.
This product is a 320240 LCD dot matrix display that can display graphics with 320 columns x 240 rows of pixels. The display uses STN mode LED backlit LCD, which displays black text on a yellow-green background, with high contrast and wide viewing angle. The module contains a driver chip and adopts COG production technology. The product is thin and light, has ultra-low power consumption, and a wide temperature range. It is connected to the main control MCU through the SPI interface and is used to display various images and texts.
Product description: The LCD12864 product STN LCD type is widely used in flow meters,...
The FSTN dot-matrix LCD screen, featuring high contrast ratio, wide viewing angle, and low power consumption, stands as the ideal display solution for high-end flow meters. This LCD display operates in FSTN mode with 128×128 or 128×64 resolution, showcasing blue-black text on a gray background with exceptional contrast and wide viewing angles. The module incorporates driver chips manufactured through COG technology, delivering slim profile, low power consumption, and broad operating temperature range. Equipped with SPI interface or 8-bit parallel LCD interface for connection to main control MCU, it delivers high-quality image and text display with stable performance.
Color film LCD is a color film combined with a fully transparent LCD to present color display content. For fixed display content, it can present the effect of a TFT color screen, and can be customized in special shapes. The price is much lower than that of a TFT color screen, the power consumption is low, and the high and low temperature performance is better than TFT. Color film LCD is usually in negative display mode and is used in combination with a backlight.
High reliability segment LCD: Different from ordinary screens, it has the characteristics of ultra-wide temperature, anti-ultraviolet, anti-vibration, high humidity, strong light visibility, low power consumption, long life, etc., and can also meet the requirements of low power consumption, suitable for battery or solar power supply conditions.
Product description: 7-inch TFT display uses automotive-grade LCD and backlight mater...
Fitness equipment such as treadmills, rowing machines, and spin bikes typically utilize LCD segment displays for their cost-effective interface. Core requirements include clarity, stability, reliability, and low power consumption. Essential display features encompass basic exercise metrics (time, speed, distance, calories burned, heart rate, preset programs, and difficulty levels), while ensuring operation in complex environments like gyms or homes with temperature variations, vibrations, and lighting changes.
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses FSTN mode, displays blue and black characters on a gray background, with high contrast and wide viewing angle. The module contains a driver chip and adopts COG production technology. The product is light and thin with low power consumption. It is connected to the main control MCU through the SPI interface or 8-bit parallel LCD interface to display various images and texts.
