Fast response optical valve LCD can quickly change the light transmission state after receiving the signal, the response speed can reach 0.1 milliseconds (100 times faster than human blink); the product is thin and light, can achieve 1.2mm thickness; the connection can be made into pins or FPC; can block infrared, ultraviolet.
The fast-response optical valve LCD is a type of twisted nematic liquid crystal that adjusts the transmission rate of incident light intensity by changing the liquid crystals deflection through an electric field. Due to its superior quality, it is widely used in welding protective glasses. When the photosensitive detector detects the welding arc, the device can switch between bright and dark modes within 0.1 milliseconds, effectively protecting the eyes of welders. The shading degree can be automatically adjusted to accommodate different welding intensities. This product typically belongs to the TN category, operates in static drive mode, and uses a fully transparent design. The color code can be customized. With a micro-ampere level power consumption, it significantly saves energy. Options include single-box and double-box configurations. Optical performance (optical grade, diffusion, uniformity, and viewing angle dependence) is rated as 1111 or 1112.
| manufacturer | EASTERN DISPLAY |
| response time | 0.1 milliseconds |
| attended mode | FPC/metal pins are customized |
| display type | TN/HTN customization |
| The perspective direction | custom made |
| working voltage | 2.7V-5V customization |
| angular field of view | 120-140° |
| Number of drive paths | STATIC |
| colour number | 3-13/112,3-13/111,3-14/111 Custom |
| Transmittance type | Transmissive |
| working temperature | - 10- 80℃ |
| storage temperature | - 30- 85℃ |
| uvioresistant | YES |
| power dissipation | Micro safe level |
| Key words: optical valve, TN LCD/HTN LCD/ fast response/electrical welding glasses/customized LCD/power saving/lightweight LCD | |
Product description: Thin LCD segment display refers to LCD with an overall thickness...
Product description: Low-power segment LCD is a display technology widely used in ele...
This product is a 240160 LCD dot matrix display that can display graphics with 240 columns x 160 rows of pixels. The display uses FSTN mode LED backlit LCD, which displays blue and black characters on a gray background, with high contrast and wide viewing angle. The module contains a driver chip and adopts COG production technology. The product is light and has low power consumption. It is connected to the main control MCU through SPI interface/I2C interface/Parallel LCD interface to display various images and texts. The product comes with a resistive LCD touch screen.
FSTN LCD Film compensated STN has a wide viewing angle, suitable for multi-channel dynamic driving, more uniform background color than STN LCD, and suitable for displaying complex screens. It can achieve 320 channels, no crosstalk, and can be made into dot matrix.
Special-shaped LCD is a non-traditional rectangular LCD display, usually designed into a circular, arc, triangle or other irregular shapes according to specific needs. This type of display has unique advantages in design and function, meeting the needs of some special fields.
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses FSTN mode LED backlit LCD, which displays blue and black characters on a gray background, with high contrast and wide viewing angle. The module contains a driver chip and adopts COG production technology. The product is light and has low power consumption. It is connected to the main control MCU through the SPI interface and is used to display various images and texts.
This product is an LCD 20×4 character dot matrix display module, which is used for ASCII character display, with 4 lines and 20 characters per line. The display screen uses STN yellow-green mode LED backlit LCD, which displays black characters on a yellow-green background, with high contrast and wide viewing angle. The module contains the ST7066 universal character driver chip, adopts COB production technology, and is connected to the main control MCU through an 8-bit parallel LCD interface, which is easy to use.
This product is a 19264 LCD dot matrix display that can display graphics with 192 columns x 64 rows of pixels. The display uses a Blue Negative Mode LED backlit LCD to display white text on a blue background with high contrast and wide viewing angle. The module contains a driver chip and adopts a COB production process. It is connected to the main control MCU through an 8-bit parallel LCD interface and is used to display various images and texts.
Product description: Reflective LCD is a liquid crystal display technology that uses ...
Product description: HTN LCD products have high contrast, wide viewing angle, clear d...
Product description: 7-inch TFT display uses automotive-grade LCD and backlight mater...
