Product description: STN LCD type is widely used in industrial instruments, industrial control equipment and communication equipment such as flow meters, microcomputer protection devices, recorders, energy meters, handheld meters, digital display meters, measuring meters, test meters, etc. Segment display digitally displays the measurement results, parameters, status information of instruments and meters, and the operating status, alarm information, and operation interface of industrial control equipment and communication equipment. EASTERN DISPLAY provides thousands of LCD displays to customers in North America, Europe, East Asia, etc. The number of COG LCDs supplied each year exceed...
STN LCD type is widely used in industrial instruments, industrial control equipment and communication equipment such as flow meters, microcomputer protection devices, recorders, energy meters, handheld meters, digital display meters, measuring meters, test meters, etc. Segment display digitally displays the measurement results, parameters, status information of instruments and meters, and the operating status, alarm information, and operation interface of industrial control equipment and communication equipment.
EASTERN DISPLAY provides thousands of LCD displays to customers in North America, Europe, East Asia, etc. The number of COG LCDs supplied each year exceeds 10 million. Based on many years of product development and production experience in serving customers of industrial instruments, industrial control equipment and communication equipment, it has rich technical accumulation in product design, core parameters and customer concerns. It can provide customers with high-quality and high-reliability STN LCD products in a continuous and stable manner.
| Manufacturer | EASTERN DISPLAY |
| Display type | STN/FSTN LCD |
| Viewing angle | 6/12 0’ CLOCK (custom made) |
| Operating voltage | 2.5V---3.3V(custom made) |
| Backlight type | LED dot matrix display |
| Backlight color | custom made |
| Operating temperature | -20℃-75℃ |
| Storage temperature | -30℃-85℃ |
| Display life | 100,000-200,000 hours (custom made) |
| ROHS standard | YES |
| REACH standard | YES |
| Applicable fields and scenarios | Flow meter, microcomputer protection device, recorder, etc. |
| Product features | Power consumption less than 50μA |
| Keywords：STN LCD/LCD display screen/LCD 16x2/LCD display 16x2/i2c LCD display/ips lcd/Dot matrix display/LCD dot matrix display/mini LCD screen/LCD1602/r LCD/LCD 12864/LCD backlight | |
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses FSTN mode LED backlit LCD, which displays blue and black characters on a gray background, with high contrast and wide viewing angle. The module contains a driver chip and adopts COG production technology. The product is light and has low power consumption. It is connected to the main control MCU through the SPI interface and is used to display various images and texts.
This product is a 19264 LCD dot matrix display that can display graphics with 192 columns x 64 rows of pixels. The display uses a Blue Negative Mode LED backlit LCD to display white text on a blue background with high contrast and wide viewing angle. The module contains a driver chip and adopts a COB production process. It is connected to the main control MCU through an 8-bit parallel LCD interface and is used to display various images and texts.
FPC LCD stands for Flexible Printed Circuit LCD. FPC is also called flexible printed circuit board, soft board, or flexible circuit board. It can be used for LCD glass lead output connection without driver chip, or COG LCD connection. No welding is required, easy to install, and the product is lightweight.
Product description: TFT LCD display screens are widely used in various commercial ve...
Product description: HTN LCD products have high contrast, wide viewing angle, clear d...
This product is a 12864 LCD dot matrix display that can display graphics with 128 columns x 64 rows of pixels. The display uses STN yellow-green mode LED backlit LCD, which displays black text on a yellow-green background, with high contrast and wide viewing angle. The module contains a driver chip, adopts COB production technology, and is connected to the main control MCU through an 8-bit parallel LCD interface to display various images and texts. The internal compensation circuit enables the module to achieve good display effects even when used in a wide temperature range.
This product is a 240128 LCD dot matrix display that can display graphics with 240 columns x 128 rows of pixels. The display uses STN Negative mode LED backlit LCD, displays white text on a blue background, and has high contrast and wide viewing angle. The module contains a driver chip, uses COB and SMT production processes, and is connected to the main control MCU through an 8-bit parallel LCD interface to display various images and texts.
COG segment LCD (Chip-on-Glass Segment Liquid Crystal Display) is a liquid crystal display technology that directly binds the driver chip (IC) to a glass substrate. It has the characteristics of high integration, light weight, low power consumption and low cost.
DFSTN (Double-layer Super Twisted Nematic) LCD is a super twisted nematic display technology based on a double-layer compensation film. The product needs to be used in conjunction with a backlight, has the characteristics of high contrast, wide viewing angle, and is suitable for dynamic display. It is widely used in medical equipment, industrial equipment, consumer electronics and other fields.
The VA segment code COG LCD module, known for its high reliability, superior optical performance, and cost-effectiveness, has become an ideal choice for display systems in small electric vehicles. This custom segment code COG module features a VA LCD screen, which is manufactured using the COG process and integrated with a driver chip. The LCD screen operates in VA mode and is connected to the main MCU via an I2C interface, using FPC (Flexible Printed Circuit) technology. This type of LCD module can be customized according to specific needs, offering high contrast, wide viewing angles, excellent display quality, a broad operating temperature range, low power consumption, a lightweight design, and stable performance.
Product description: Ultra-wide temperature LCD segment code screen is a kind of LCD ...
This product is an LCD 20×4 character dot matrix display module, which is used for ASCII character display, with 4 lines and 20 characters per line. The display screen uses STN yellow-green mode LED backlit LCD, which displays black characters on a yellow-green background, with high contrast and wide viewing angle. The module contains the ST7066 universal character driver chip, adopts COB production technology, and is connected to the main control MCU through an 8-bit parallel LCD interface, which is easy to use.
This product is an LCD 16×2 character dot matrix display module, which is used for ASCII character display, with 2 lines and 16 characters each. The display screen adopts FSTN mode LED backlit LCD, which displays blue and black characters on a gray background, with high contrast and wide viewing angle. The module contains a character driver chip, adopts COG production technology, is thin and light, and has low power consumption. It is connected to the main control MCU through the SPI interface or 8-bit parallel LCD interface.
Product description: Ultra-small size segment LCD is a display technology widely used...
Product description: Compared with TN LCD, HTN LCD, STN LCD, and FSTN LCD, VA LCD has...
This product is a full-LCD automotive instrument cluster featuring a large-sized TFT screen with a resolution of 1920×720, an LVDS interface, an IPS wide-viewing-angle display, and an LED backlight with a brightness of 1000 cd/m². It maintains clear visibility even in bright light conditions. It supports wide temperature operation from -30°C to 80°C, is compatible with complex electromagnetic environments, and meets the stringent requirements of the automotive industry. It is widely used in the front-mounted instrument panels of heavy-duty trucks, light-duty trucks, buses, and new energy passenger vehicles.
